Lashing- and connection device at road vehicles for sea transport on Ro/Ro ships
Lashing point forged in one piece,v
100% crack detected
Acc. to EN 29367-2, Resistance characteristics with a proof force = 120 kN and a breaking force = 200 kN
Simple attachment with three bolts M12, quality 10.9
Surface: galvanised
Shapely design, appropriate to the load
Lightweight construction
Suitable for all common lashing means
The force contact point at the bracket has been chosen in such a way that the direction of load is in the centre of gravity of the bolts. Advantage: Minimising the load of the bolt, permitting the use of a smaller bolt dimension.
